The online conductivity analyzer (salinity) consists of a controller and a conductivity sensor. The sensor outputs an RS485 signal, and its interference suppression capability is stronger when used on site. The controller has analog, digital, switching, and other output interfaces.
Manufacturer: eom SOLUTIONS GmbH | Messtechnik - We measure everything that flows.
| Technical specifications |
Sensors |
| Measurement parameters |
Conductivity (salinity), temperature |
| Range |
Conductivity:(0~500) mS/cm, salinity:(0~100) ppt
Temperature:(0~60) ℃ |
| Accuracy |
≤ ± 1 % |
| Repeatability |
≤ 1 % |
| Resolution |
0,01μS/cm |
| Zero drift |
≤ ± 1 % F. S |
| Span drift |
≤ ± 1 % F. S |
| Response time |
≤ 20s |
| Temperature compensation accuracy |
≤ ± 1 % |
| Calibration cycle |
3 months |
| Protection level |
IP68 |
| Supply voltage |
(12/24) V DC |
| Power consumption |
<0.3 W |
| Communication mode |
RS485(Modbus RTU), maximum baud rate 115200 bps |
| Overall dimension |
156mm × φ28mm |
| Weight |
0.3 kg |
| Material |
POM |
| Technical Specifications |
Controller |
| Display/Resolution |
4 inch industrial color TFT display (800*480
resolution) |
| Controller size |
144 mm * 144 mm * 115 mm |
| Power supply |
(85~265) V AC |
Power
consumption |
2.5 W |
| Storage temperature |
(-20~70)°C |
| Working temperature |
(-10~60)°C |
| Protection level |
IP55 |
| Analog output |
2 (4~20)mA analog outputs, maximum load 500 ohms |
| Relay |
3-way relay (120VAC,24VDC/1A) |
| Digital output |
1 RS485 output, 1 RS232 output |
| Material |
ABS |
- Monitoring the water quality of the process for treating wastewater and industrial wastewater and the discharge
- Monitoring the water quality of drinking water intake and process treatment
- Monitoring surface water and groundwater
