Level TROLL 400 Datalogger

Product No.:: LVTR400

Price on request

Add to wish list

Ask about product

DESCRIPTION

Unless you require vented level data, the Level TROLL 400 is for you. This low-maintenance data logger measures and logs water level, water pressure and temperature. Ideal for long-term monitoring at flood-prone or high-humidity sites, the Level TROLL 400 is available in non-vented (absolute) pressure ranges. 3D factory calibration and our unique anti-drift system ensure accuracy, and durable titanium construction is designed to withstand harsh conditions in fresh or saltwater, in either groundwater or surface water environments.

As part of In-Situ's shared ecosystem, this versatile instrument easily integrates with accessories and in-well telemetry. Pair with In-Situ's VuLink telemetry and HydroVu Data Services for powerful remote data access and management. Smart addressing enables you to connect any device to the same data logger without reprogramming to monitor the same parameter.

MODELLVARIANTEN

11 m (30 psia)
0-70 m (100 psia)
200 m (300 psia)
341 m (500 psia)

RESPONSIBILITY
We are responsible for ensuring that you receive the right equipment. Your use, measurement and evaluation should provide exactly the data you need. In-Situ's products require more consulting than other items. We assemble your product so that you get the data you need. Do not hesitate to contact us.

TECHNICAL SPECIFICATIONS

General	Level TROLL 400	Level TROLL 500	Level TROLL 700	Level Baro TROLL
Temperature ranges	Operational: -20 to 80° C Storage: -40 to 80° C Calibrated: -5 to 50° C	Operational: -20 to 80° C Storage: -40 to 80° C Calibrated: -5 to 50° C	Operational: -20 to 80° C Storage: -40 to 80° C Calibrated: -5 to 50° C	Operational: -20 to 80° C Storage: -40 to 80° C Calibrated: -5 to 50° C
Diameter	1.83 cm	1.83 cm	1.83 cm	1.83 cm
Lenght	21.6 cm	21.6 cm	21.6 cm	21.6 cm
Weight	124 g	124 g	124 g	124 g
Materials	Titanium body Delrin nose cone	Titanium body Delrin nose cone	Titanium body Delrin nose cone	Titanium body Delrin nose cone
Output Options	Modbus/RS485, SDI-12, 4 to 20 mA	Modbus/RS485, SDI-12, 4 to 20 mA	Modbus/RS485, SDI-12, 4 to 20 mA	Modbus/RS485, SDI-12, 4 to 20 mA
Battery Type	3.6V lithium	3.6V lithium	3.6V lithium	3.6V lithium
External Power	8 to 36 VDC	8 to 36 VDC	8 to 36 VDC	8 to 36 VDC
Memory	2.0 MB	2.0 MB	4.0 MB	1.0 MB
Fastest Logging rate	2 per sec.	2 per sec.	4 per sec.	1 per min.
Fastest output rate	Modbus: 2 per sec. SDI-12 & 4 to 20 mA: 1 per sec.	Modbus: 2 per sec. SDI-12 & 4 to 20 mA: 1 per sec.	Modbus: 2 per sec. SDI-12 & 4 to 20 mA: 1 per sec.	Modbus: 2 per sec. SDI-12 & 4 to 20 mA: 1 per sec.
Log Types	Linear, Fast Linear, and Event	Linear, Fast Linear, and Event	Linear, Fast Linear, Linear Average, Event, Step Linear, True Logarithmic	Linear
